| Sản phẩm | PSU Nguồn máy tính |
| Hãng sản xuất | SILVERSTONE |
| Model (safety certification) | SST-ST1200-PTS |
| Color | Black(Lead-Free Paint) |
| Max. DC Output | 1200W |
| Power density | 664W per liter |
| Load Range | |
| +3.3V |
- Max.(Amps): 25A
- Min (Amps): 0A - Range (%): ±3% - Line Reg.(%): ±1% - Ripple(mVp-p): 50mV |
| +5V | - Max.(Amps): 22A - Min (Amps): 0A - Range (%): ±3% - Line Reg.(%): ±1% - Ripple(mVp-p): 50mV |
| +12V | - Max.(Amps): 100A - Min (Amps): 0.15A - Range (%): ±3% - Line Reg.(%): ±1% - Ripple(mVp-p): 120mV |
| +5VSB | - Max.(Amps): 3A - Min.(Amps): 0A - Range (%): ±5% - Line Reg.(%): ±1% - Ripple(mVp-p): 50mV |
| -12V | - Max.(Amps): 0.3A - Min (Amps): 0A - Range (%): ±10% - Line Reg.(%): ±1% - Ripple(mVp-p): 120mV |
| Combined +3.3V & +5V | 120W |
| Combined +12V | 1200W |
| Input Voltage | 100V~264V |
| Input Frequency Range | 47Hz~63Hz |
| PFC | Active PFC(PF>0.9 at full load) |
| Efficiency | 89%~92% at 20%~100% loading |
| MTBF | 100,000 hours |
| Operating temperature | 0°C ~ 40°C |
| Protection | - Over power protection - Over current protection - Over voltage protection - Over Temperature protection - Under voltage protection - Short circuit protection |
| Connectors | - 1 x 24 / 20-Pin motherboard connector(”600mm”) - 1 x 8 / 4-Pin EPS / ATX 12V connector(”550mm”) - 1 x 8 / 4-Pin EPS / ATX 12V connector(”750mm”) - 8 x 8 / 6-Pin PCIE connector(”550mm/150mm” X4) - 8 x SATA connector("600mm /150mm / 150mm / 150mm" X2) - 6 x 4-Pin Peripheral connector(”600mm / 150mm / 150mm” X2) - 2 x 4-Pin Floppy connector(”150mm” X2) |
| Cooling System | Single 120mm HYB fan |
| Noise Level | 18 dBA minimum |
| Certification | 80 PLUS Platinum |
| Form factor | ATX |
| Dimension | 150 mm (W) x 86 mm (H) x 140 mm (D) |
| Weight | 2kg |
| Other | - GPU Support list - Compatible with ATX12V v2.4 |
